FLIR CM85 User Manual

FLIRCM85USERMANUALDocumentIdentifier:CM85‐en‐US_AB
10
4.2FunctionSwitch
Themetercanmeasurecapacitancethroughtheprobeinputs.
Themetercanmeasureresistance,continuity,ordiodepolaritythroughthe
probeinputs.ThetypeofmeasurementisselectedbytheMODEbutton.
Themetercanmeasurepowerthroughtheprobeinputsandtheclamp
jaws.
Themetercanmeasurecurrentthroughtheclampjaws.
Themetercanmeasurevoltagethroughtheprobeinputs.
Themeterisinfullpower‐savingmode.
4.3FunctionButtons
 UsethebuttontoselectAutoselectorManualselectmode,seesection
5.2Auto/Manualselectmode
 InManualselectmode,pressthebuttontoselecttheoperatingmode
 UsethebuttontoselectAutorangeorManualrangemode,seesection
5.3Auto/Manualrangemode
 InManualrangemode,pressthebuttontochangetherange(scale)
 PressthebuttontotogglebetweenNormalandHoldmodes,seesection
5.4Holdmode
 Holdingthebuttondownfor2secondsenables/disablesthekeylock
mode
 InHoldmode,themeterwillbeepcontinuouslyandthedisplaywill
flashifthemeasuredsignalislargerthanthe
displayreading(forthe
V.A.W.function).
 Pressthebuttontoenable/disablethedisplaybacklight.
 Pressandholdthebuttonfor2secondstoenable/disabletheworklight.
Pressthebuttontoenable/disableMETERLiNK®(Bluetooth®)
communication,seesection5.13Streamingmeasurementdatausing
Bluetooth

