FLIRCM85USERMANUALDocumentIdentifier:CM85enUS_AB
16
TIME
CURRENT
0A
Start Stop
Current
Detection
Threshold
Measured Inrush
Current
100ms Sample Window (60Hz)
5.6.3.2PeakMode
InPeakmode,themetercapturesanddisplaysthepositive andnegativepeakvalues,and
updatesonlywhenahigher/lowervalueisregistered.Peakmodeisavailablewhen
measuringACcurrentorvoltageinManualselectmode.
Usethenavigationbuttonstoselect andenablePeakmode.
PresstheOKbuttontotogglebetweenthedisplayofPeakMaxandPeakMin.
1. InPeakMaxmode,the indicatorisdisplayed.
InPeakMinmode,the
indicatorisdisplayed.
PressandholdtheOKbuttonfor2secondstodisablePeakmode.
5.6.3.3InRushCurrentMode
InInrushcurrentmode,themeterdisplaysthehighestcurrentreadinginthefirst100ms
afterthetriggerpoint(currentdetectionthreshold,seeFig.5.3below).Thecurrent
detectionthresholdis1.00Aforthe100.00Arangeand10.0Aforthe1000.0Arange.Inrush
currentmodeisavailablewhenmeasuringACcurrent
inManualselectmode.
1. Connectthemetertotheunpoweredcircuitundertest
2. SetthemetertoA
3. Usethenavigationbuttonstoselect
andenableInrushcurrentmode.
4. Turnonthepowertothecircuitundertest
Note:Iftheinrushcurrentundertestingismorethan100AAC,manuallysettherangeto
600Abeforeactivatingtheinrushcurrentmode,seesection5.3Auto/Manualrangemode.
Figure5.3InrushCurrent
