4.4 DisplayIconsandIndicators

IndicatesthatMETERLiNK®(Bluetooth)communicationisactive.

IndicatesthatthemeterisinAutoselectmode,seesection5.2
Auto/Manualselectmode..

Indicatesthatthemeterisdisplayingmaximumreadingvalues.

Indicatesthatthemeterisdisplayingminimumreadingvalues.

Indicatesthatthemeterisdisplayingtheaveragereading.

Indicatesthatthemeterisdisplayingpeakmaximumvalues.

Indicatesthatthemeterisdisplayingpeakminimumvalues.

IndicatesthatthemeterisinAutorangemode.

IndicatesthatthemeterisinPowerfactormode.

Indicatesthatthemeterdisplaysthetotalharmonicdistortion.
