4.4DisplayIconsandIndicators

IndicatesthatthemeterisinAutoselectmode.

Indicatesthatthemeterisdisplayingmaximumreadingvalues.

Indicatesthatthemeterisdisplayingminimumreadingvalues.

Indicatesthatthemeterisdisplayingtheaveragereading.

Indicatesthatthemeterisdisplayingpeakmaximumvalues.

Indicatesthatthemeterisdisplayingpeakminimumvalues.

IndicatesthatthemeterisinAutorangemode.

IndicatesthatthemeterisinPowerfactormode.

Indicatesthatthemeterdisplaysthetotalharmonicdistortion.

IndicatesthatthemeterisinPhaserotationmode.

IndicatesthatthemeterisinHoldmode.
