FLIR CM85 - 5.6.3.4 DC Zero Mode; 5.6.3.5 Frequency Mode

FLIRCM85USERMANUALDocumentIdentifier:CM85‐en‐US_AB
17

5.6.3.4DCZeroMode
TheDCzerofeatureremovesoffsetvaluesandimprovestheaccuracyforDCcurrent
measurements.DCZeromodeisavailablewhenmeasuringDCorAC+DCcurrentinManual
selectmode.
1. Ensurethatthereisnoconductorintheclampjaws.
2.
Usethenavigationbuttonstoselect andenableDCZeromode.
5.6.3.5FrequencyMode
InFrequencymode,themetermeasuresanddisplaysthefrequency.Frequencymodeis
availablewhenmeasuringACcurrentorvoltageinManualselectmode.
Importantnote:DonotswitchtotheFrequencymodeuntilthemeterissetupand
activelymeasuringthevoltageorcurrentsignal.
Usethenavigationbuttonsto
select andenableFrequencymode.
