18
OPERATION (continued)
USER CONFIGURATION MODE (continued)
PIN Menu
The first menu in the configuration mode is for the user to enter a Personal Identification
Number (PIN) to secure the configuration of the computer and continue with making changes.
The default user PIN is 0000. Using this default PIN will unlock the meter unless the PIN has
been reset by the user.
The initial user PIN entry screen will show 0000.
The left most digit will be flashing ON/OFF to
indicate focus if the user wants to change the
PIN. (See Figure 14-1)
Figure 14-1
If the entered PIN was incorrect, the screen
momentarily displays “Entry Denied” (See Figure
14-2) then returns automatically to normal
operation display.
Figure 14-2
NOTE: Using the user default PIN, or the user specific PIN (if previously reset), and
advancing focus to the next menu, the software will compare the entered PIN with the PIN
stored in the computer. If a match is found, the next menu will be shown allowing the user
to reset the PIN if desired.
Reset PIN Menu
If the PIN was entered correctly, the next menu will be displayed and allow reset of the PIN
if desired. (See Figure 15-1)
Figure 15-1 Figure 15-2
The “N” will be in focus (flashing). To decline resetting the PIN, advance focus to next menu.
To reset the PIN, increment the “N” to “Y” (see figure 15-2) and advance focus to next screen.
(See Figure 16)
To Next Page
