12
OPERATION
NORMAL OPERATION MODE
Button Usage Map – Normal Operation Mode
BUTTON
Button Operation (Normal Operation Mode)
Total Button: Change between batch total and accumulative total.
When a total is displayed, pressing the Total button changes the top row of large display
digits between batch total and accumulative total. The information row will change to the
proper units and the corresponding icons will be shown, i.e. TOTAL or BATCH TOTAL.
(See Figures 7-1 and 7-2)
(Batch Total-Litres) (Accumulative Total-Gallons)
Figure 7-1 Figure 7-2
