Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~14~
Chapter 3 External Views, Part Names and Functions
The mechanical design parts/assembly of the
machine are grouped according to its function;
namely, the print head carriage, the x-axis
movement mechanism, the y-axis movement
mechanism, the roll media feeding and take-up
mechanism, the ink supply compartment, the
electrical control cabinet and the printing platform.
The printing system control is a modular control
that has the dedicated controller board for a specific function. Other controller board functions as a stand-alone
control, like the roll media feeding and take-up control board, that has no communication and no interlock with
the other controller board, it needs only the power supply from the machine. The mechanics, the electronics
and the standard electrical parts are harnessed together to form a system for large format printing application.
LJII-series Perspective View
Fig.3-1Top View
(Back Side)
(Front Side)
Fig.3-2 Left View
Ink Supply Control
To Next Page
