FLORA LJ3208P - Take-Up System & Feeding System; Power Control Panel

Flora Digital Printing System
Model LJ320P
Copyright 2011@ Shenzhen Runtianzhi Image Technology Co.,Ltd. By Victor Xu
~17~
3.7 Take-up System & Feeding System
Take-up system in the front of the machine is used to roll up the output media, while the feeding
system fixed behind the machine used for roll down the media for feeding.
3.8 Power Control Panel
Power control panel is fixed behind the machine on the right side! On this panel, there is one inlet
used for main power input, three built-in outlets two of which are used for computer and monitor.
All the power breakers are also built on this panel!
Fig.3.7-1 Take-up System
Tension Ba
r
Take-up Rolle
r
Motor Box
Fig.3.7-2 Feeding System
Feedin
g
Motor
Feedin
g
Roller
Media Hoop
Fig.3.7-3 Control Panel
Back Heat Controller
Take-up Switch
Transition
Button
Feedin
g
Switch
Fig.3.8-1 Power Control Panel
Main power Breaker
Computer outlet
Main Power Inlet
S
y
stem Breaker
Heatin
g
Breaker
Monitor Outlet
Backup Outlet
