- 31 -
5.2.5 Pulse Menu
The pulse is used for an external totalizer. The value of the pulse is used to set the signification of each pulse for
the totalizer contact output.
Note: The duration of the closing contact is fixed to 100 msec. This means that the limit
(frequency of contact closure) is set at maximum 5 contacts per second.
If the flow is bigger, a faulty alarm will turn on and the totalizer contact ouput is closed.
Example: With a flow of 1 l/s and a pulse every 5 l.
Figure 20: Contact totalizer output for 1l/s and a pulse each 5l.
Implementing pulse value:
1. Select “Pulse“ in the “Main Menu”, then press
2. Enter the value for the pulse using the arrows , , & then press
Note: The unit of the pulse is configured in the “Unit Menu”, refer to section 5.2.3
5.2.6 Time Menu
5.2.6.1 Set the timezone
Select “Time“ in the “Main Menu”, then press
1. Press the up or down arrows until the correct timezone is reached, then press
Note: For countries that use summer and winter time, the timezone must be changed manually.
Note: For countries that have a timezone different that an integer, press to select minutes and
then use the up & down arrows to adjust the timezone by 15 min.
