- 19 -
3.2.3.7 Measurement data „read only“
Adresse Modus Länge Typ Einheit Bezeichnung Kommentar
Address
Mode
Length
Type
Unit
Description
Comment
1000
R
2
float32
m/s
Velocity vQP
Velocity considering the quality parameters
1002
R 2 float32 m/s Velocity vQPMF
Velocity considering the quality parameters and
the median filter
1004
R
2
float32
m/s
Velocity vAVG
Average velocity
1006
R
2
float32
m/s
Velocity vRAW
Raw surface velocity
1008
R 1 unsigned16
Sensor
identification
=0x0001 (RAVEN-EYE)
=0x0014 (BELUGA 20°)
=0x002D (BELUGA 45°)
1009
R
1
signed16
VSN
Quality parameter (Velocity Spectrum Number)
1010
R
2
float32
SNR
Quality parameter (Signal to Noise Ratio)
1012
R
1
signed16
AGC
Quality parameter (Automatic Gain Control)
1013
R
1
signed16
NOT
Quality parameter (Number Of Trials)
1014
R
2
float32
°C
Temperature
Internal temperature of the sensor
1016
R
2
float32
%
Humidity
Internal humidity of the sensor
1018
R
2
float32
Bar
Pressure
Internal pressure of the sensor
1020
R 2 float32
Standard deviation
(σ)
Quality parameter
1022
R
2
float32
Amplitude (A)
Quality parameter
1024
R
2
float32
m
Level (h)
1026
R
2
float32
l/s
Flow rate (Q)
1028
R
1
unsigned16
Status
Table 4: Registers to be read
3.3 Connect the power source
DANGER
Electrocution hazard. Hazardous supply voltage can shock or cause death. Do not connect AC power
to a DC Monitor.
1. Check all connections.
2. Screw back the bottom panel cover.
3. Tighten screws on cover.
4. Connect the power source.
3.4 Record the installation measurements
1. Document the site specific data (location, site ID and description).
2. Enter the installation date.
3. Record the serial numbers of the monitor and sensor.
4. Record pipe inside dimension (ID) number.
5. Record the level offset or level calibration as appropriate. Refer to the sensor manual for the installed
sensor.
6. Record the sediment level if applicable.
