2.3 Unpack the instrument
Remove the IFQ Monitor from the shipping carton. Inspect for any visible damage. If an item is missing or
damaged, contact your direct representative or Flow-Tronic S.A.
2.4 Front panel
Refer to Figure 1 for the IFQ Monitor panel features
Figure 1: IFQ Monitor features
1 LEDs 5 Cable glands
2 Display 6 Navigation keys
3 Cover attachment screw 7 Side channel cover access
4 Bottom cover
3
4
5
6
2
7 1
