Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM
Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790
E-mail : info@flow-tronic.com | www.flow-tronic.com
- 3 -
1 Specifications
Specifications are subject to change without notice.
Housing
Dimensions
285 x 250 x 145 mm
Weight
2.0 kg
Enclosure
ABS plastic (Acylonitrile-Butadine-Styrene), NEMA 4
Operating temperature
-25 to 55 °C
Storage temperature
-30 to 65° C
Operating humidity
Max 90% r.H. ; not condensing
Protection
IP65
Power requirements
AC
85-265 VAC, 47- 63 Hz, max. 25 W, incl. sensors.
DC
9-36 VDC, max. 25 W, incl. sensors.
General
Sensor interface
RS485 digital sensor interface for RAVEN-EYE
®
or BELUGA
TM
Display
144x32 pixel white-on-blue graphical display.
Two lines of text display scrolling between: FLOW, VELOCITY, LEVEL and TOTAL FLOW
Internal battery status indication.
LED
6 status indication LEDs.
Outputs
3x analog output 4-20 mA ; 10 bits, up to 250 Ohm load : FLOW, VELOCITY and LEVEL
2x relay output ; Rating: 6A at 30 VDC / 6A at 250 VAC : TOTAL IMPULSE and ALARM
Supported sensors
Velocity: RAVEN-EYE
®
or BELUGA
TM
Level: ULS-02, ULS-06; RLS-15, PLS-02 or PLS-06
Inputs
1x 4…20 mA analog input for level sensor (ULS-02, ULS-06 or other external level sensor)
Logger (optional)
Memory: 2 Gb
Type: Flash memory (SD card)
File format: .tsv
Communication (opt.)
Modbus RTU (slave) over RS485 communication port
Setup & operation
7 position sealed membrane keypad
Certifications
CE, RoHs
Warranty
Warranty
1 year from date of shipment.
