2.5 Stroke Output
Table 5: Stroke Output
Feedback Shaft Rotation
Min 15°, Max 90° 45° recommended for linear
applications.
2.6 Remote Mount Specifications
Table 6: Remote Mount Specifications
NOTE: For entity parameters, see section 3 HAZARDOUS AREA
CERTIFICATIONS.
Remote Mount Device
Use only with Logix® Remote
Mount Option device.
Max Cable and Tube Distance 30.5 m (100 ft)
Operating Temperature -52 to 85°C (-61.6 to 121°F)
2.7 Limit Switch Specifications
Table 7: Limit Switch Specifications
NOTE: For entity parameters, see section 3 HAZARDOUS AREA
CERTIFICATIONS.
Switch Specifications
Mechanical
Cherry DG 13-B(X)RA
NO and/or NC
General Purpose Only
Load Current 3/2 AAC/ADC
Voltage 125/30 VAC/VDC
Temperature
-25 to +85 °C
(-13 °F to 185 °F)
Reed
Hamlin 59050-030
NO
Load Current 500 mA
Voltage 200VDC
Temperature
-40 to +105 °C
(-40 °F to 221 °F)
Inductive Sensor
P&F NJ2-V3-N
NAMUR NC -3
Load Current
Plate: ≤ 1 mA;
No Plate: ≥ 3 mA
Voltage Nominal 8.2 VDC
Temperature
-25 °C to 100 °C
(-13 °F to 212 °F)
Inductive Proximity
P&F SJ2-S1N
NAMUR NO-4
Load Current
Plate: ≤ 1 mA;
No Plate: ≥ 3 mA
Voltage 5-25 VDC (Nominal 8 VDC)
Temperature
-25 °C to 100 °C
(-13 °F to 212 °F)
Inductive Proximity
P&F SJ2-SN
NAMUR NC-5
Load Current
Plate: ≤ 1 mA;
No Plate: ≥ 3 mA
Voltage 5-25 VDC (Nominal 8 VDC)
Temperature
-40 °C to 100 °C
(-40 °F to 212 °F)
Inductive Sensor
P&F NBB2-V3-E2
PNP NO
General Purpose Only
Load Current 0…100 mA
Voltage 10...30 VDC
Temperature
-25 °C to 70 °C
(-13 °F to 158 °F)
2.8 V to I Board Specifications
Table 8: V to I Board Specifications
Board Input Voltage Resulting Current
Shut-Off Voltage 10 VDC ~0 mA
Working Voltage 19 - 26 VDC ~12 to 24 mA
2.9 Positioner Performance Characteristics
Table 9: Performance Characteristics
Better than or equal to the following values on a 25 square inch Mark I
actuator.
Resolution £ 0.25%
Linearity +/-1.25%
Repeatability £ 0.25%
Hysteresis £ 1.0%
Deadband £ 0.3%
Sensitivity £ 0.25%
Stability £ 0.4%
Long term drift £ 0.5%
Supply Pressure Effect £ 0.2%
NOTE: Performance tested according to ISA 75.13.
2.10 Physical Specifications
Table 10: Physical Specifications
NOTE: For dimensions, see section 20 POSITIONER .
Housing Material
Cast, powder-painted aluminum EN
AC-AlSi12(Fe)
Soft Goods Fluorosilicone
Weight of Base Positioner Without
Accessories
With Single Acting Relay 1.76 kg
(3,88 lb) With Double Acting Relay
1.88 kg (4.14 lb)
2.11 Temperature
Table 11: Temperature
Operating Temperature Range
(w/o switches)
-52 to 85°C (-61.6 to 185°F)
Transport and Storage Range -52 to 85°C (-61.6 to 185°F)
NOTE: Reduced performance possible at low temperatures.
