Logix

®

520MD+ and 510+ Digital Positioners FCD LGENIM0105-15-AQ – 05/16

26

Port

Relay

(Single Acting)

Spool Style

Relay

(Double Acting)

Spool Style

Relay

(Single Acting)

S Supply Supply Supply

B Y1 Y2 (Plug)

A (Plug) Y1 Y1

Figure 24: Pneumatic Connections
