Flowserve Logix 520MD+ User Manual

Logix
®
520MD+ and 510+ Digital Positioners FCD LGENIM0105-15-AQ – 05/16
82
21.4 VDI/VDE 3847 Mounting Blocks
Table 32: VDI/VDE 3847 Mounting Block (Aluminum)
Relay
Type
No.
Gages
Gage Internal
Material
Pressure Units Part-no.
Poppet 0 N/A N/A 307308.999.000
Poppet 2 Brass PSI (Bar/kPa) 307309.999.000
Poppet 2 Brass PSI (kg/cm2) 307310.999.000
Poppet 2 Stainless PSI (Bar/kPa) 307311.999.000
Poppet 2 Stainless PSI (kg/cm2) 307312.999.000
Spool 0 N/A N/A 307313.999.000
Spool 3 Brass PSI (Bar/kPa) 307314.999.000
Spool 3 Brass PSI (kg/cm2) 307315.999.000
Spool 3 Stainless PSI (Bar/kPa) 307316.999.000
Spool 3 Stainless PSI (kg/cm2) 307317.999.000
21.5 Mounting Kits
Table 33: Mounting Kits
Description Part-no.
Shaft Converter - D to NAMUR 314586.999.000
Direct Mount – 500MD+
(IEC 534 part 6 FlowTop, Kämmer KA, Kämmer
KP, and standard NAMUR linear valves)
307303.999.000
