User Manual F012-P
Page 48 FW_F012-P_M_v0501-01_EN
POWER REQUIREMENTS
Type PB
SAFE AREA ONLY - Standard lithium primary battery. Life up to 5 years.
Type PC
INTRINSICALLY SAFE - Certified lithium primary battery. Life up to 5 years.
Type PD 16-30 V DC. Max power consumption 1 W.
Type PF 24 V AC/DC ±10%. Max power consumption 15 W.
Type PM 115-230 V AC ±10%. Max power consumption 15 W.
Type PX 8-30 V DC. Max power consumption 0.3 W.
Type ZB Separate power for backlight. 20-30V DC, max power consumption 1 W.
Not needed with Type PF or PM.
Note with Type PF or
PM
Total consumption of sensor, transistor output type OA and backlight type ZB may not exceed
400 mA @ 24 V DC.
Note with I.S.
applications
For intrinsically safe applications, consult the safety values in Section 7.2: Electrical
installation in hazardous areas[»37]
SENSOR EXCITATION
Type PB/PC/PX
Only for very low power sensing. Sensor supply 3.2 V DC for pulse signals and 1.2 V DC for
coil pick-up.
Type PD Additional to Type PX sensor excitation: 8.2 V DC, max. 5 mA.
Type PF/PM Additional to Type PX sensor excitation: 8.2, 12 or 24 V DC, max 400 mA @ 24 V.
TERMINAL CONNECTIONS
Type Removable plug-in terminal strip. Wire max 1.5 mm
2
and 2.5 mm
2
DATA PROTECTION
Type EEPROM backup of all settings. Data retention at least 10 years.
Password Configuration settings can be password protected
DIRECTIVES AND STANDARDS
EMC EN 61326-1 FCC 47 CFR part 15
Low Voltage EN/IEC 61010-1 CSA C22.2 No.61010-1 UL61010-1
ATEX EN IEC 60079-0 EN 60079-11
IECEx IEC 60079-0 IEC 60079-11
CSA c-us CAN/CSA C22.2 No.157 ANSI/UL 913
CAN/CSA C22.2 No.142 UL 508
CAN/CSA C22.2 No.60079-0 ANSI/ISA-60079-0
CAN/CSA C22.2 No.60079-11 ANSI/ISA-60079-11
FM FM Class 3600 ANSI/UL 60079-0
FM Class 3610 ANSI/UL 60079-11
FM Class 3810
RoHS EN 50581 IEC 63000
IP & NEMA EN 60529 ANSI/IEC 60529 NEMA 250
Note See the applicable Declaration of Conformity or product certificate for specific revisions and
publication dates of applicable standards.
