APPENDIX A - TECHNICAL SPECIFICATION
A.1 GENERAL
DISPLAY
Type High intensity reflective numeric and alphanumeric LCD, UV-resistant
Digits 7 with height 17mm (0.67”) and 11 with height 8mm (0.31”). Various symbols and measuring
units.
Dimensions 90 x 40 mm (3.5” x 1.6”)
Refresh rate User definable: fast - 1 sec - 3 sec - 15 sec - 30 sec - off
Type ZB (option) LED backlight with adjustable intensity
ENCLOSURES
General Die-cast aluminum, Stainless Steel 316L or GRP (Glass Reinforced Plastic) wall / field mount
enclosure with polycarbonate window, silicone and EPDM gaskets.
UV stabilized and flame retardant material.
Control keys Industrial type microswitches. UV resistant silicone keypad.
Coating UV resistant 2 component industrial coating (aluminum enclosure only)
Panel mount
Dimensions
Panel cut-out
Protruding front
Classification
Type HC
Type HB, HSB
130 x 120 x 60mm (5.10” x 4.72” x 2.38”) – WxHxD
115 x 98mm (4.53" x 3.86") – WxH
31mm (1.22")
IP65 / NEMA Type 4X
GRP enclosure. Weight 450gr.
Aluminum / Stainless Steel enclosure. Weight 0.6 / 1 kg (1.3 / 2.2 lbs).
Field or wall mount
Dimensions
With extended back
Classification
Weight (approx.)
130 x 120 x 75mm (5.10” x 4.72” x 2.95”) – WxHxD
130 x 120 x 90mm (5.10” x 4.72” x 3.54”) – WxHxD
IP67 / TYPE 4X
GRP 0.6 kg / 1.3 lbs
Aluminum 1 kg / 2.2 lbs
Stainless steel 1.5 kg / 5.5 lbs
Aluminum / SS
Type HA
Type HB/HSB
Type HL
Type HM/HBM/HSM
Type HN
Type HO/HBO/HSO
Type HP
Type HT
Type HU/HBU/HSU
Type HV
Type HZ
Cable entries (threaded) - HS_ indicates stainless steel, HB_ indicates extended back
2 x PG9 – 1 x M20
Panel mount front cover only
2 x ½”NPT
2 x M16 – 1 x M20
1 x M20
2 x M20
6 x M12
1 x ½”NPT
3 x ½”NPT
4 x M20
No cable entries
GRP (plastic)
Type HC
Type HD
Type HE
Type HF
Type HG
Type HH
Type HJ
Type HK
Cable entries (no threading)
Panel mount front cover only
No cable entries
2 x 16mm (0.63”) – 1 x 20mm (0.78”)
1 x 22mm (0.87”)
2 x 20mm (0.78”)
6 x 12mm (0.47”)
3 x 22mm (0.87”)
Flat bottom - no cable entries
OPERATING TEMPERATURE
Safe area -40°C to +80°C (-40°F to +178°F)
Intrinsically safe -40°C to +70°C (-40°F to +158°F)
For EPL Da: -40°C to +50°C (-40°F to +122°F)
