F012-P User Manual
FW_F012-P_M_v0501-01_EN Page 7
3.2.3 OPTIONS
Available options are:
● Intrinsic safety (Type XI)
● Power and sensor supply (Types PB, PC, PD, PF, PM, PX, in various combinations)
● Panel mount enclosure (Types HB, HC)
● Flame-proof enclosure (Type XF)
● Display backlight (Type ZB).
3.3 INSTALLATION EXAMPLE
Following parts can be recognized in below installation example.
1
3
2
4
5
6
Fig.3: Installation example F012-P
1. Front cover 3. Label 5. Keys
2. Display 4. Back cover 6. Cable entry (process mount)
