Measuring Current
1
7
Measuring Current
Determine how the current from an outlet is supplied to a load, in this example,
a hair dryer.
1
Open the main menu.
2
3
Make connections as shown below:
4
Turn on the hair dryer.
When the hair dryer is turned on, the current from the outlet increases.
Notice that without test leads connected, the Fluke 43B measures the
frequency of the current signal.
VOLTS
AMPS
HERTZ
