Fluke 43B - Using FlukeView Software

Fluke 43B
Applications Manual
22
Measuring Current Harmonics
Non-linear loads produce current harmonics which may cause voltage
distortion.
1
Open the main menu.
2
3
Select AMPS.
4
Make connections as shown below:
(5)
Scale the harmonics spectrum screen to see more or less
details.
 HARMONICS


