Fluke 43B Application Guide

Fluke 43B
Applications Manual
26
Recording the Load on a Transformer
By recording the kVA during several hours, you can find out if there are specific
moments during the day that the transformer may become overloaded.
1
Open the main menu.
2
3 Open the RECORD menu.
Select the desired record time:
4
5
Select the first reading to record:
6
7
Repeat step 6 and 7 to select the second
reading, or continue with step 8.
 POWER
 RECORD TIME
8 hours 
 FIRST READING
VA 

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
