Fluke 43B Application Guide

Fluke 43B
Applications Manual
16
Detecting Transients (Phase to Neutral)
Disturbances in a distribution system may cause malfunctioning of many types
of devices. For example, resetting computers or false tripping breakers. Events
occur occasionally, making it necessary to monitor the system for a period of
time to find them.
You may look for voltage transients (impulses or spikes) when, for example,
computers are resetting spontaneously.
1
Open the main menu.
2
3
A transient is detected when it
crosses the boundaries of the
waveform.
Select a voltage change of 50%.
If the normal rms voltage is 120V, transients
which deviate more than 60V from the normal
voltage, are detected. (50% of 120V = 60V).
4
 TRANSIENTS


 VOLTAGE CHANGE (%rms)
50 % 

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
