Fluke 43B Application Guide

Handling Screens and Data
Recording Harmonics over Time
6
73
6
Click Start to start recording the harmonics.
FlukeView will display the actual reading and in the
background all the readings are logged in memory.
7
Click this button to stop recording.
8
Click this button to save the recorded values in an ASCII file
format (.CSV or .TXT).
9
You can now open the saved file using a spreadsheet
program to analyze the saved data.

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
