5080A
Service Manual
12
Phase
Specification, 1 year, tcal ±5 °C, ±(ΔΦ)
[1][2]
45 TO 65 Hz 65 to 500 Hz 500 Hz to 1 kHz
0.25 ° 1.5 ° 5.0 °
[1] See Power and Dual Output Limit specifications for applicable outputs.
[2] Phase settling times are typically <18 seconds additional.
Phase (Φ) Watts Phase (Φ) VARs
PF
Power Factor Adder due to Phase Error, ±(%)
45 to 65 Hz 65 to 500 Hz 500 Hz to 1 kHz
0 ° 90 °
1.000 0.00 % 0.03 % 0.38 %
10 ° 80 °
0.985 0.08 % 0.50 % -
20 ° 70 °
0.940 0.16 % 0.99 % -
30 ° 60 °
0.866 0.25 % 1.55 % -
40 ° 50 °
0.766 0.37 % 2.23 % -
50 ° 40 °
0.643 0.52 % 3.15 % -
60 ° 30 °
0.500 0.76 % 4.57 % -
70 ° 20 °
0.342 1.20 % 7.23 % -
80 ° 10 °
0.174 2.48 % 14.88 % -
90 ° 0 °
0.000 - - -
Notes
To calculate exact ac watts power factor adders due to phase error for values not shown, use the following formula:
()
()
Adder
Cos
Cos
%(
()
=−
+
100 1
ΦΔΦ
Φ
)
For example, for a PF of 0.9205 (Φ = 23) and a phase specification of ΔΦ = 0.15, the ac watts power factor adder is:
()
()
%11.0)
23
)15.(23
1(100% =
+
=
Cos
Cos
Adder
Calculating Power Specifications
The Overall specification for power output in watts (or VARs) is based on the root sum square (rss) of the individual
specifications in percent for the selected voltage, current, and power factor or VARs parameters:
Watts specification
PFadder
2
current
2
voltagepower SpecSpecSpecSpec
2
++=
VARs specification VARsadder
2
current
2
voltageVARs SpecSpecSpecSpec
2
++=
Because there are a tremendous number of combinations, you should calculate the actual power specification for your
selected voltages and currents. The method of calculation is best shown in the following examples (using 1-year
specifications):
Example 1 Output: 100 V, 1 A, 60 Hz, Power Factor = 1.0 (Φ=0), 1-year specifications
Voltage Specification Specification for 100 V at 60 Hz is 0.14 % + 18 mV, totaling:
100 V x 0.0014 = 140 mV added to 18 mV = 158 mV. Expressed in percent:
158 mV/100 V x 100 = 0.158 % (see “AC Voltage Specifications”).
Current Specification Specification for 1 A at 60 Hz is 0.10 % + 1200 μA, totaling:
1 A x 0.001 = 1000 μA added to 1200 μA = 2.2 mA. Expressed in percent:
2.2 mA/1 A x 100 = 0.22 % (see “AC Current Specifications”).
PF Adder Watts Adder for PF = 1 (Φ=0) at 60 Hz is 0 % (see “Phase Specifications”).
Total Watts Output Specification =
%27.0022.0158.0
22
power
=++=
2
Spec
Example 2 Output: 100 V, 1 A, 50 Hz, Power Factor = 0.5 (Φ=60), 1-year specifications
Voltage Specification Specification for 100 V at 50 Hz is, 0.14 % + 18 mV, totaling:
100 V x 0.0014 = 140 mV added to 18 mV = 158 mV. Expressed in percent:
158 mV/100 V x 100 = 0.158 % (see “AC Voltage Specifications”).
Current Specification Specification for 1 A is 0.10 % + 1200 μA, totaling:
1 A x 0.001 = 1000 μA added to 1200 μA = 2.2 mA. Expressed in percent:
2.2 mA/1 A x 100 = 0.22 % (see “AC Current Specifications”).
