5080A
Service Manual
44
Required Calibration Test Equipment
Table 29 shows the test equipment necessary.
Table 29. Test Equipment Required for Calibration
Quantity Manufacturer Model Equipment
1 Fluke 8508A Reference Multimeter
1 Fluke 5790A or 5790B AC Measurement Standard
1
Fluke A40B 10 mA, 50 mA, 20 A, 2 A, 1 A, and
200 mA current shunts
1 Fluke 742A-1k Resistance Standard, 1 kΩ
1 Fluke 742A-100 Resistance Standard, 100 Ω
1 Fluke 742A-10 Resistance Standard, 10 Ω
1 Fluke 742A-1 Resistance Standard, 1 Ω
1 Guildline 9230 0.01 Ω shunt
1 Fluke PN 900394 Type N Dual Banana Adapter
1 Fluke 792-7004 A40 Current Shunt, Adapter
1 Fluke 742A-1M Resistance Standard, 1 MΩ
1 Fluke 742A-10M Resistance Standard, 10 MΩ
1 Guildline 9334/100M Resistance Standard, 100 MΩ
Start Calibration
To start a calibration:
1. Push .
2. Push the CAL softkey twice.
3. Push the 5080A CAL softkey.
Note
The CALIBRATION SWITCH on the Product rear panel can be in
either position when you begin calibration. It must be set to ENABLE
to store the correction factors into nonvolatile memory.
After you push the 5080A CAL softkey, the procedure works as follows:
1. The Product automatically programs the outputs and prompts you to make
external connections to applicable measurement instruments.
2. The Product then goes into Operate mode, or prompts you to place it into
Operate mode.
3. You are then prompted to type in the value read on the measurement
instrument.
Note
To redo a step, push the OPTIONS, and BACK UP STEP softkey, or
skip over a step by pressing the SKIP STEP softkey
