Fluke 5080A Service Manual

5080A
Service Manual
6
International ........................................................ IEC 61326-1: Basic Electromagnetic Environment
CISPR 11: Group 1, Class A
Group 1: Equipment has intentionally generated and/or uses
conductively-coupled radio frequency energy that is necessary for
the internal function of the equipment itself.
Class A: Equipment is suitable for use in all establishments other
than domestic and those directly connected to a low-voltage power
supply network that supplies buildings used for domestic purposes.
There may be potential difficulties in ensuring electromagnetic
compatibility in other environments due to conducted and radiated
disturbances.
Emissions that exceed the levels required by CISPR 11 can occur
when the equipment is connected to a test object.
Korea (KCC) ....................................................... Class A Equipment (Industrial Broadcasting & Communication
Equipment)
Class A: Equipment meets requirements for industrial
electromagnetic wave equipment and the seller or user should take
notice of it. This equipment is intended for use in business
environments and not to be used in homes.
USA (FCC) .......................................................... 47 CFR 15 subpart B. This product is considered an exempt device per
clause 15.103.
Line Power
Line Voltage (selectable) .................................... 100 V, 120 V, 220 V, 240 V
Line Frequency ................................................... 47 to 63 Hz
Line Voltage Variation ......................................... ±10 % about line voltage setting
Power Consumption................................................ 600 VA
Dimensions
Height.................................................................. 19.3 cm (7.6 in)
Width ................................................................... 43.2 cm (17 in), 44.3 cm (17.5 in) including handles
Depth .................................................................. 53.8 cm (21.2 in)
Weight ..................................................................... 22 kg (48 lb)
Specification Definition ............................................ The specifications include stability, temperature coefficient, linearity,
line and load regulation, and the traceability of the external standards
used for calibration. It is not necessary to add anything to determine
the total specification for the temperature range indicated.
Specification Confidence Level ............................... 99 %
Detailed Specifications
DC Voltage
Range
Specification, tcal ±5 °C
±(% of output + μV)
Stability
Resolution (μV)
Max Burden
[1]
90 days 1 year
24 hours, ±1 °C
±(% of output + μV)
0 to 329.999 mV 0.011 % + 10 0.013 % + 10 0.0035 % + 6 1
60 Ω
0 to 3.29999 V 0.008 % + 15 0.010 % + 15 0.0025 % + 10 10 300 mA
0 to 32.9999 V 0.008 % + 150 0.010 % + 150 0.0025 % + 100 100 600 mA
10 to 101.999 V 0.010 % + 1500 0.012 % + 1500 0.003 % + 1000 1000 300 mA
30 to 329.999 V 0.010 % + 1500 0.012 % + 1500 0.003 % + 1000 1000 120 mA
100 to 1020.00 V 0.010 % + 5500 0.012 % + 5500 0.003 % + 5000 10000 40 mA
Auxiliary Output (dual output mode only)
0 to 329.99 mV 0.10 % + 1000 0.12 % + 1000 0.03 % + 300 10 5 mA
0.33 to 3.2999 V 0.10 % + 1000 0.12 % + 1000 0.03 % + 300 100 5 mA
3.3 to 7.000 V 0.10 % + 1000 0.12 % + 1000 0.03 % + 300 1000 5 mA
[1] Remote sensing is not provided. Output resistance is 60 Ω for outputs <330 mV. Output resistance is <5 mΩ for outputs ≥0.33 V.
The AUX output has an output resistance of <1 Ω.
