Calibrator
Specifications
11
DC Power Summary
Time Voltage
Currents
0.33 to 3.2999 mA 3.3 to 329.99 mA 0.33 to 2.9999 A 3 to 20.5 A
Specification, tcal ±5 °C, ±(% of watts output)
[1]
90 days 33 mV to 1020 V 0.14 0.11 0.21 0.52
1 year 33 mV to 1020 V 0.15 0.11 0.22 0.54
[1] To determine the actual dc power specification, see the individual “DC Voltage Specifications”, “DC Current Specifications”, and
“Calculating Power Specifications” sections. The actual specification at the operating point will usually be significantly better than
the table value, since the specifications state the minimum performance for the voltages and currents listed.
AC Power Summary
Time Voltages
Currents
3.3 to 8.9999 mA 9 to 32.999 mA 33 to 89.99 mA 90 to 329.99 mA
Specification, tcal ±5 °C, 45 to 65 Hz, PF = 1, ±(% of watts output)
90 days
33 to 329.999 mV 0.56 0.43 0.56 0.43
330 mV to 1020 V 0.50 0.34 0.50 0.34
1 year
33 to 329.999 mV 0.58 0.45 0.58 0.45
330 mV to 1020 V 0.51 0.36 0.51 0.36
Currents
0.33 to 0.8999 A 0.9 to 2.1999 A 2.2 to 4.499 A 4.5 to 20.5 A
Specification, tcal ±5 °C, 45 to 65 Hz, PF = 1, ±(% of watts output)
90 days
33 to 329.999 mV 0.57 0.43 0.54 0.69
330 mV to 1020 V 0.51 0.35 0.47 0.64
1 year
33 to 329.999 mV 0.59 0.46 0.56 0.72
330 mV to 1020 V 0.52 0.37 0.49 0.67
Notes
To determine the actual ac power specification, see the individual “AC Voltage Specifications”, “AC Current Specifications”, “Phase
Specifications”, and “Calculating Power Specifications” sections. The actual specification at the operating point will usually be
significantly better than the table value, since the specifications state the minimum performance for the voltages and currents listed.
Power and Dual Output Limits
Frequency Voltages (NORMAL) Currents Voltages (AUX) Power Factor (PF)
DC
0 to ±1020 V 0 to ±20.5 A 0 to ±7 V
-
45 to 65 Hz 33 mV to 1000 V 3.3 mA to 20.5 A 100 mV to 5 V 0 to 1
65 to 500 Hz
330 mV to 1000 V 33 mA to 2.9999 A 100 mV to 5 V 0 to 1
3.3 V to 1000 V 33 mA to 20.5 A 100 mV to 5 V 0 to 1
500 Hz to 1 kHz 330 mV to 1000 V 33 mA to 20.5 A 100 mV to 5 V 1
Notes
The range of voltages and currents shown in “DC Voltage Specifications”, “DC Current Specifications”, “AC Voltage Specifications”, and
“AC Current Specifications” are available in the power and dual output modes, except that the minimum current for AC power is 0.33 mA
However, only the voltages and currents shown in this table are specified. See “Calculating Power Specifications” to determine the
specification at any points within this table.
The phase adjustment range for dual AC outputs is 0 ° to ±179.9 °. The phase resolution for dual AC outputs is 0.1 degree.
Power and dual output amplitude settling times are typically <9 seconds.
