Calibrator

Performance Tests

Table 12. Verification Tests for Phase (Normal Voltage vs. Aux Voltage)

Range Output Frequency

Range, AUX

Output

Voltage

Output

AUX

Phase

Lower

Limit

Upper

Limit

3.3 V 329 mV 65 Hz 3.29999 V 329 mV 0 ° -0.25 ° 0.25 °

3.3 V 329 mV 65 Hz 3.29999 V 329 mV 60 ° -0.25 ° 0.25 °

3.3 V 329 mV 65 Hz 3.29999 V 329 mV 90 ° -0.25 ° 0.25 °

3.3 V 100 mV 500 Hz 3.29999 V 100 mV 0 ° -1.5 ° 1.5 °

3.3 V 330 mV 1 kHz 3.29999 V 330 mV 0 ° -5.00 ° 5.00 °

Table 13. Verification Tests for Distortion

Range, Normal Output Output Lower Limit Upper Limit

0.000 % @ 3 V 45 Hz 0.00 % 0.00 % 0.22 %

0.000 % @ 3 V 100 Hz 0.00 % 0.00 % 0.22 %

0.000 % @ 30 V 45 Hz 0.00 % 0.00 % 0.52 %

0.000 % @ 30 V 1 kHz 0.00 % 0.00 % 0.52 %

0.000 % @ 100 V 100 Hz 0.00 % 0.00 % 0.53 %

0.000 % @ 100 V 1 kHz 0.00 % 0.00 % 0.53 %

Table 14. Verification Tests for Frequency

Range Output Nominal Lower Limit Upper Limit

3.29999 V 1.00000 V 100.0000 Hz 99.993 Hz 100.007 Hz

MEGOHM Option Verification Tests

The verification test points in Tables 15 through 17 are to be used as a guide

when you re-verify the Calibrator. There is no built-in factor for measurement

uncertainty. The tables are for approved metrology personnel who have access

to a standards laboratory that has equipment that can test calibration equipment

of this level of accuracy.
