NetTool
Users Manual
4-6
Obtaining a Device’s IP Address Information
To obtain IP address information for a device, do the
following:
1. Select Addresses Used to display the following:
Figure 4-7. Addresses Used Screen
The Addresses Used screen enables you to verify a
devices’ IP address information. This screen also
displays the best-discovered name for the device as
well as its IP, IPX, and MAC address.
2. CDP (Cisco Discovery Protocol) information, if found,
is also given on this screen. Press the Down
b
arrow key to locate the CDP section, as shown in
Figure 4-8:
Figure 4-8. CDP Information
CDP information is reported for the most recently
received CDP advertisement on that side. This
information is updated every two seconds.
When plugged into a switch VLAN port, information
for Native VLAN and Appliance (phone) VLAN are
also given.
