NetTool
Users Manual
B-4
Typical Cisco Skinny (SCCP) Call Log
Following is a sample SCCP call log. Events in the exchange are shown on the left. Commentary appears on the right to help
you follow the sequencing of the exchange. The log captures an entire phone transaction, starting with the phone going OFF
HOOK:
CallMgr:129.196.197.244
OFF HOOK
Keypad: 2
Keypad: 0
Keypad: 0
Keypad: 2
// Call manager IP address
// Phone goes off hook
// x2002 is dialed
PROCEED
>2000,Blade Lab
<2002,
// Call manager acknowledges
/ /the two parties in the call
RING OUT
CONNECTED
// far end is ringing
// far end has picked up
>2000,Blade Lab
<2002,
START MEDIA XMIT // media transmission is to start
G711 Ulaw64k
Call Setup: 104ms
// the CODEC being used
// the time from CONNECTED to RTP
To Next Page
