Fluke TiX500 - Controls

Expert Series Thermal Imagers
Product Familiarization
7
Controls
Table 3 shows the connections of the Imager.
Table 3. Connections
7
6
5
1
2
3
4
Item Description Item Description
Lithium-ion Smart Battery Anchor for Neck Strap
Smart Battery Port 2-Bay Battery Charging Base
Micro SD Memory Card Slot
AC Power Supply with Universal
Adapte
rs
Tripod Mount


 



