TiX500, TiX520, TiX560, TiX580
Users Manual
26
To use the distance measurement feature:
1. Turn on the distance feature and set the units to show on the display.
2. Point the Imager at the target.
3. Push the Laser Distance Finder button.
shows at the top of the display.
4. Position the red laser dot on the target.
5. Release the Laser Distance Finder button.
The distance measurement shows on the bottom of the display. The measurement shows
as “- - - -” when the Imager cannot take a measurement. If this is the case, use a tripod or
steady the Imager and retake the measurement. If there is excessive laser movement, an
error message shows on the display due to an out of range distance.
Camera Menu
Table 13 lists the options in the Camera menu
Table 13. Camera Menu
Option Menu Option Description
LaserSharp
Autofocus
On
Turns on LaserSharp Autofocus to automatically focus on a
target. See LaserSharp Auto Focus System.
Off
Turns off LaserSharp Autofocus to use the Advanced manual
focus. See LaserSharp Auto Focus System.
Backlight <options> Select to set the brightness level of the display.
Torch -- Turns on/off the built in flashlight.
Video
Video/Audio
Select to record video and audio.
Note
A Bluetooth headset is required and the radio must
be enabled for voice (audio) recording. This feature
may not be available in all regions.
Video ONLY Select to record video only.
Record Video Select to start recording a video. See Video.
