TiX500, TiX520, TiX560, TiX580
Users Manual
14
Measurement Menu
Table 9 lists the options in the Measurement menu.
Table 9. Measurement Menu
Option Menu Option Description
Range <options>
Select the temperature range from one of the preset
measurement ranges or to a fully automatic range.
Set Level/Span
Auto
Sets the Level/Span to adjust automatically or manually.
Manual
Set Level/Span
With Level/Span set to Manual, changes the Level/Span.
See Level/Span.
Line Temp <options> Turns on/off the Line Temp.
Emissivity
Adjust Number
Sets a custom emissivity value when a value from the
standard emissivity table is not appropriate for the
measurement. See Emissivity Adjustment.
Select Table
Select an emissivity value from a list of common materials.
See Emissivity Adjustment.
Background <options>
Changes the background temperature to compensate for
reflected background temperature.
Very hot objects or very cold objects can affect the
apparent temperature and measurement accuracy of the
target, especially when surface emissivity is low. Adjust
the reflected background temperature to improve the
accuracy of the measurement.
Note
If Display is set to Display All, the background
temperature shows as BG = xx.x on the
display.
