Follett 12CI400A-LI - Dispense chute and splash panel (models with SensorSAFE infrared dispensing) - Serial Number D61292 and above

36 12CI400A • 12HI400A
Reference # Description Part #
1 Chute, ice or water (with Agion) 00967760
2 Sensor (includes lens and Ty-rap*) 00122978
3 Support, water tube 00960682
4 Screw, panel 00982421
5 Fitting, bulkhead (with nut) 00976787
6 Tube, water solenoid 502420
Not shown Splash panel, without drain pan (includes 2 Ty-raps and 2 lenses) 00981357
7 Splash panel, (includes 2 Ty-raps and 2 lenses) 00981332
8 Lens, sensor (each) 502690
Not shown Splash panel, ice only (includes 1 Ty-raps and 1 lens) 00981340
9 Solenoid, assembly (includes ttings, screws) 00981209
* Ty-rap is a registered trademark of Thomas & Betts International, Inc.
7
8
8
2
2
1
1
6
5
4
3
5
Dispense chute and splash panel (models with SensorSAFE infrared dispensing) —
Serial Number D61292 and above
