40 12CI400A • 12HI400A
Ice machine components
Reference # Description Part #
1 Drier 502724
2 Coil, condenser 501187
3 Water sensor 502116
4 Float valve & reservoir 500504
Not shown Elbow, 1/4", push-in 00121699
Not shown Adapter, female thread to 1/4" push-in 00998716
Not shown Fitting, plastic, oat valve (includes sleeve & stem) 502078
5 Compression nozzle, single drain 502221
6 Evaporator (see page 40 for detailed drawing) —
Not shown Shroud, condenser coil 501820
7 Drain pan, evaporator 502727
8 Valve, expansion, thermal 502726
Not shown Valve, shut-off, water, brass 502222
9 Valve, shut-off, water, plastic 502921
10 Gearbox & motor, 115 V, 60 Hz (includes 307192) 00142034
Not shown Strainer, water, threaded connections 500376
11 Strainer, water, push-in connections 502920
12 Fan blade 500474
13 Motor, fan, 115 V, 60 Hz 500672
14 Bracket, fan motor 501188
15 Overload, compressor, 115 V, 60 Hz 502782
16 Compressor, 115 V, 60 Hz 502731
17 Water line with Agion, evaporator 00141432
18 Tubing, polypropylene, reservoir supply (sold by the foot) 502079
19 Bracket, oat valve 502383
20 Tube, ice transport 00168112
21 Insulation, ice tube, 12" (305 mm) required 501176
22 Bracket, gearmotor mounting 307192
23 Cord and plug, power 502776
24 Hi-pressure cut-out 502732
25 Clip, water shut-off valve 502922
Not shown Elbow, water, 3/8" 502925
26 Tee, water, 1/4" 502923
Not shown Gasket, ice hose 00977322
27 Pinch clamp 00988238
28 Drain tube with Agion, reservoir overow 00980151
29 Drain tube with Agion, hopper/evaporator drain pan 00980144
Not shown Tubing, plastic, 5/8 ID, bin drain tube before SN# B72959 (sold by the foot) 500623
Not shown Adapter, 3/4" x 5/8" (Before SN# B72959) 00114199
Ice machine cleaner/descaler and sanitizer
Part# Description
00132001 SafeCLEAN environmentally friendly ice machine cleaner, carton of 24 x 7 oz packets
00979674 Nu-Calgon IMS-II Sanitizer, 16 oz. bottle
