Follett 12CI400A-LI - Dispense chute and splash panel (models with lever dispensing) - Serial Numbers below D61292

12CI400A • 12HI400A 37
4
5
5
4
8
6
9
2
16
16
3
1
2
7
1
15
10
water solenoid assembly
12
13
11
14
Dispense chute and splash panel (models with lever dispensing) —
Serial Numbers below D61292
Reference # Description Part #
1 Chute, ice, with bracket and fasteners (with Agion) 00981225
1 Chute assembly (clear), ice 502513
2 Chute, water, with bracket and fasteners (with Agion) 00981233
2 Chute (clear), water 502249
3 Lever 502417
4 Thumbscrew 501100
5 Switch, dispense 502409
6 Boot, dispense switch button (mounts over the dispense button) 502418
7 Fastener, dispense chute assembly 502057
8 Screws, dispense lever 501250
9 O ring 502427
10 Fitting, 1/4" tube 502561
11 Fitting, 3/8" tube 502562
12 Support bracket, solenoid 502419
13 Valve, solenoid water 502243
14 Tube, water solenoid 502420
15 Solenoid, assembly (includes solenoid, ttings, tube & mounting bracket) 502421
16 Cover, dispense assembly 502819
17 Splash panel 00172767
