33
TCP/IP Setting
Open the [MFR-TALM Web-based Control: Port Settings page] and perform port settings
under TCP/IP Port.
Port
Menu
[Port Settings] - [TCP/IP Port]
Access
Method
IP Address
Port
Function
Web-based Control
[TALM Settings]
Client
(MV
IP address)
(MV TCP/IP
port number)
TSL UMD protocol
V5.0 Tally out
Encode
DLE
Screen No.
Unicode
ON
(Set the same as in
MV)
Settings for data transmission between HVS-390HS and MFR-TALM
<HVS-390HS side>
To apply the name data received from the MFR system on the switcher, set [LINK] to
[MFR] in the [SETUP - EXT I/F - ROUTER] (6/6) menu.
Perform the TALLY COLOR and TALLY UNIT settings so that the MFR-TALM unit can
receive switcher tally data.
<MFR-TALM side>
Open the [MFR-TALM Web-based Control: HVS-TAL Protocol Reception page] and
perform the same tally settings as those in HVS-390HS.
Setting Example)
In the switcher's TALLY COLOR menu, set the TALLY COLOR for the M/E1 PGM bus to
RED. Then, assign RED TALLY IN01-IN08 to Tally Out Pin 1-8 for a Tally Unit.
Open the [MFR-TALM Web-based Control: HVS-TAL Protocol Reception page] and set
the same tally settings. Now the MFR system can receive the relevant tally data from the
switcher.
The MFR system can transmit the received tally data to the multiviewer in which these
tally and name data are displayed, or use them for GPI outputs on MFR-GPI or
MFR-TALM .
- To display the received data on the multiviewer screen, assign the same bus and signal
sources used in the switcher in the multiviewer's [DP-MV Tally page].
- To use the received data for GPI outputs, perform Tally Out settings in the [GPI Pin
Assign page] of the MFR Web-based Control.
The tally settings in the MFR system must be entered in the [MFR-TALM Web-based
Control: Tally System Settings page]. When using MFR-TALM for tally control, the [Main
unit Web-based Control: Tally System Settings page] and its subpages are all disabled.
Refer to your multiviewer's user guide for the details on how to handle tally data on the
multiviewer.
