39
Product in compliance with relative CE regulations.
Double insulation. This symbol means that you cannot get at any element without
using a tool. Tools which have this symbol have not any earthing protection
systems.
It is forbidden to place your hands in the area marked with this sign, while the
machine is running. Injury Hazard!
ELECTRICAL CONNECTION
ELECTRICAL CONNECTIONS
Use 230 V 50 Hz alternate voltage equipped with a ground conductor to supply your machine.
Ensure that the power supply corresponds to this voltage, that it is protected by a differential
and magnetic thermal switch, and that the ground system is efficient. If your machine does not
work when connected to a socket, check carefully the power supply features.
EXTENSION CABLES
Only use three conductors extension cables, with a plug with two plugs and a ground contact
and sockets with two holes and a earth corresponding to the plug of the tool. When using an
electric tool at a remarkable distance from the power supply, use an extension cable with
sufficient dimensions to transport the current which the tool needs. If the extension cable has
not the sufficient dimensions a voltage drop can occur, thus causing an overheating and a
voltage loss. You can only use extension cables which are in compliance with CE standards.
Extension cable length: up to 15 m
Cable dimensions: 3 x 2,5 mm²
Before using any kind of extension cable, check that it has not bare wires and that the
insulation is not cut or worn. Repair and change immediately it if it is damaged or worn.
WARNING:
Extension cables must be arranged away from the working area in order that they do not get in
touch with the work-pieces, the tool or other parts of the machine, thus creating possible risks.
Indicates that this machine is equipped with a laser pointing device (see par.
SAFETY INSTRUCTIONS FOR THE POINTING DEVICE).
Serial number / year of production
