Page #40 background imageLoading...
Page #40 background image
40
WARNING:
KEEP THE TOOLS AND THE EQUIPMENT AT A SAFE DISTANCE FROM CHILDREN
RECOMMENDED USE
This tool has been designed for cross and radial cutting wood and similar materials.
With the saw blade in a vertical position the maximum cutting height is 105 mm and the
maximum cutting width is 340 mm.
The head of the mitre saw can rotate from 0° to 45° both on the right and on the left for angle
cutting. The saw blade can be inclined at 45° on the left for inclined cutting.
The machine capacities are listed in the technical specifications table.
The machine is steady enough, however, it can be fixed onto a bench.
TECHNICAL SPECIFICATIONS
Engine power: 2000 W
Voltage and frequency: 230 V - 50 Hz
Speed: 5500 min¯¹
Saw blade maximum dimensions: 305 x 3.2 x 30 mm
Crosscut at 90°: 105 x 340 mm
Oblique cutting 45°, left and right: 105 x 240 mm
Inclined cutting 45° left: 65 x 340 mm
Inclined cutting 45° right: 40 x 340 mm
Composed cutting (cross and bevel 45° right): 40 x 240 mm
Composed cutting (cross and bevel 45° left): 65 x 240 mm
Left and right stops: 0° - 15° - 22.5° - 30° - 45°
Inclination stops: 0 and 45°
Net weight: 23 kg
Gross weight: 25 kg
Machine dimensions: 835 x 570 x 790 mm
Carton dimensions: 915 x 570 x 535 mm
NOISE CONDITIONS
The noise emitted, measured in conformity with the standards EN 3744 and EN 11201 is:
- Sound pressure level LpA = 101 dB(A)
- Sound power level LWA = 114 dB(A)
- Uncertainty of measurement K = 3 dB
We recommend you to use ear protection devices.
The sources of the noise of the saw are: the electric engine and its ventilation system, the blade
and the material to be cut.
We advise you to control the engine, its ventilation system and the aspiration passages. As far
as the saw blade is concerned, it is preferable to use silenced type of blades and to keep them
in good conditions. We recommend to use the correct saw blade and to keep firmly the work-
piece to be cut.
Noise levels are emission levels and do not necessarily indicate safe working conditions. Even if
