52
CUTTING WITHOUT SLIDING DEVICE
When cutting a narrow piece, the sliding device is not needed.
In this case, block the sliding device in the back position by tightening the sliding control knobs
and cut traditionally, pulling down the head onto the piece
When the cut is finished, release the trigger keeping the head down until the disk comes to a
complete stop; then lift the head to the upper position
CUTTING CURVED MATERIALS
Check the piece before cutting: if it is curved , place the piece on the base as described in the
following picture:
WARNING!
If you cut the wrong way, the piece could suddenly move and cause injuries to the
user
ANGLE CUTTING
1. Lift the arm to the upper position.
2. release the base rotation knob and turn the base according to the desired angle, holding
the operating handle
3. stand aligned to the new position of the head to cut.
WARNING!
Before angle cutting or bevel cutting, extend the extensions on both sides, to
prevent the disk from touching them.
