51
WARNING!
- Do not cross arms in the disk area while cutting.
Make sure that the base and the angles are blocked before cutting.
CUTTING A WOOD PIECE
WARNING!
Before starting to cut, make sure the mitre saw has been correctly assembled and
set. Make sure you have red and understood all the safety instruction included in this
manual
To cut a piece:
1. Lift the head to its higher position.
2. Select your desired angle and block the knob.
3. Select your desired bevel inclination angle and block the knob.
4. Make sure that the piece dimensions are suitable with the mitre saw.
5. Hold strongly the piece on the base, using the vertical and horizontal clamps
6. Hold strongly the wide pieces to prevent them from tilting; in case of need use the lateral
extensions.
7. Check that your hands are away from the disk path.
8. Pull the arm towards you, along the sliding guides, holding the operating handle.
9. Press the trigger to start the machine and wait until the disk has reached its maximum
speed.
10. Slowly lower the disk through the piece and let the disk slide in the opposite direction to
cut all along the piece. Do not put high pressure on the disk: your cut will be more efficient
and precise if the disk turns at the correct speed.
11. Release the trigger, wait for the disk’s complete stop and lift the arm to the upper position
after the cut is done.
WARNING!
Do not cut metal with your mitre saw. This machine is not granted for metal
cutting. The manufacturer is not responsible for problems caused by the misuse of the
machine.
CORRECT USE OF THE SLIDING DEVICE
Note: it can be dangerous to cut pulling the head towards you: the disk could “climb” in the
material and raise towards yourself. Always push the disk in the opposite direction, away from
you, when you slide-cut. The following points describe how to slide-cut correctly:
1. Place the piece on the base of the mitre saw, against the cut-end guide. Hold the
operating handle, without pressing the trigger.
2. Pull the arm towards you, keeping the arm in the upper position. Then press the trigger to
start the machine.
3. Push the protection locking button and push the operating handle.
4. Push the arm towards the cut-end guide, to complete the cut.
5. Release the trigger and keep the arm down until the disk comes to a complete stop.
6. Once the disk stops, lift the head in its higher position.
