RADIAL MITRE SAW IDENTIFICATION
A. Operating Handle
B. Laser on-off switch
C. Starter trigger
D. Lower Blade protection
E. Blade
F. Vertical operating clamp
G. Extensible supports
H. Double beam Laser
I. Plane insert
J. Bevel cut rotation handle
K. Rotating base graduation
L. Horizontal operating clamp
M. Cut-end guide
N. Rotating base
O. Bevel graduation
P. Bevel locking device
Q. Sliding guide
R. Vertical Cut-end regulation
S. Dust bag
T. Engine
U. Upper blade protection
