SPECIFICATIONS
SubDrive 15 Connect/SubDrive 20 Connect
52
SubDrive 15 Connect/SubDrive 20 Connect
* Operating temperature is specified at full output power when installed as recommended. Refer to
“Over Temperature Foldback” on page 34.
** Shelf life can be extended for one year by powering the drive for 60 minutes with no load.
SubDrive 15 SubDrive 20
Model
NEMA 3R
(indoor/outdoor)
5870205103C 5870205303C
Input from
Power Source
Voltage 208/230 ± 10% VAC 208/230 ± 10% VAC
Phase In Single-Phase Single-Phase
Frequency 60/50 Hz 60/50 Hz
Current (max) 12 A 19 A
Power Factor ~ 0.95 ~ 0.95
Power (idle) 4 Watts 5 Watts
Power (max) 2.5 kW 4.2 kW
Wire Gauge Size(s)
Refer to
“Fuse/Circuit Breaker and Wire Sizing” on
page 20.
Refer to “Fuse/Circuit Breaker and Wire Sizing” on
page 20.
Output to
Motor
Voltage 272 VAC Maximum 272 VAC Maximum
Phase Out Single-Phase (3-Wire) OR Three-Phase Single-Phase (3-Wire) OR Three-Phase
Frequency Range
30-78 Hz: 1/2-rated pump (Three-Phase)
30-70 Hz: 2/3 or 3/4-rated pump (Three-Phase)
30-60 Hz: Matched pump (Three-Phase)
30-63 Hz (Single-Phase Motors)
30-78 Hz: 1/2-rated pump (Three-Phase)
30-70 Hz: 2/3 or 3/4-rated pump (Three-Phase)
30-60 Hz: Matched pump (Three-Phase)
30-63 Hz (Single-Phase Motors)
Current (max)
5.9 A / phase
8.1 A / phase
Wire Gage Size(s)
Refer to “Maximum Motor Cable Length” on
page 21.
Refer to “Maximum Motor Cable Length” on
page 21.
Pressure
Setting
Factory Preset 50 psi (3.4 bar) 50 psi (3.4 bar)
Adjustment Range
Transducer: 5-95 psi (0.3-6.6 bar)
Pressure Sensor: 25-80 psi (1.7-5.5 bar)
Transducer: 5-95 psi (0.3-6.6 bar)
Pressure Sensor: 25-80 psi (1.7-5.5 bar)
Operating
Conditions*
Temperature
(at 230 VAC input)
–13 °F to 122 °F (–25 °C to 50 °C) –13 °F to 122 °F (–25 °C to 50 °C)
Relative Humidity 20-95%, non-condensing 20-95%, non-condensing
Storage**
Temperature –13 °F to 149 °F (–25 °C to 65 °C) –13 °F to 149 °F (–25 °C to 65 °C)
Shelf Life 1.5 Years 1.5 Years
Dimensions
and Weight
NEMA 3R
9-3/4” x 19-3/4” x 5-1/4” : 26 lbs
(25 x 50 x 13 cm) : (11.8 kg)
9-3/4” x 19-3/4” x 5-1/4” : 26 lbs
(25 x 50 x 13 cm) : (11.8 kg)
