Franklin Electric MonoDrive - Subdrive 30 Connect;Subdrive 50 Connect

SPECIFICATIONS
SubDrive 30 Connect/SubDrive 50 Connect
53
SubDrive 30 Connect/SubDrive 50 Connect
* Operating temperature is specified at full output power when installed as recommended. Refer to
“Over Temperature Foldback” on page 34.
** Shelf life can be extended for one year by powering the drive for 60 minutes with no load.
SubDrive 30 SubDrive 50
Model
NEMA 3R
(indoor/outdoor)
5870205403C 5870205503C
Input from
Power Source
Voltage 208/230 ± 10% VAC 208/230 ± 10% VAC
Phase In Single-Phase Single-Phase
Frequency 60/50 Hz 60/50 Hz
Current (max) 23 A 36 A
Power Factor ~ 0.95 ~ 0.95
Power (idle) 5 Watts 7 Watts
Power (max) 4.2 kW 7.2 kW
Wire Gauge Size(s)
Refer to
“Fuse/Circuit Breaker and Wire Sizing” on
page 20.
Refer to “Fuse/Circuit Breaker and Wire Sizing” on
page 20.
Output to
Motor
Voltage 272 VAC Maximum 272 VAC Maximum
Phase Out Single-Phase (3-Wire) OR Three-Phase Single-Phase (3-Wire) OR Three-Phase
Frequency Range
30-78 Hz: 1/2-rated pump (Three-Phase)
30-70 Hz: 2/3 or 3/4-rated pump (Three-Phase)
30-60 Hz: Matched pump (Three-Phase)
30-63 Hz (Single-Phase Motors)
30-78 Hz: 1/2-rated pump (Three-Phase)
30-70 Hz: 2/3 or 3/4-rated pump (Three-Phase)
30-60 Hz: Matched pump (Three-Phase)
30-63 Hz (Single-Phase Motors)
Current (max) 10.9 A / phase 17.8 A (three-phase), 17.0 A (single-phase)
Wire Gage Size(s)
Refer to “Maximum Motor Cable Length” on
page 21.
Refer to “Maximum Motor Cable Length” on
page 21.
Pressure
Setting
Factory Preset 50 psi (3.4 bar) 50 psi (3.4 bar)
Adjustment Range
Transducer: 5-95 psi (0.3-6.6 bar)
Pressure Sensor: 25-80 psi (1.7-5.5 bar)
Transducer: 5-95 psi (0.3-6.6 bar)
Pressure Sensor: 25-80 psi (1.7-5.5 bar)
Operating
Conditions*
Temperature
(at 230 VAC input)
–13 °F to 122 °F (–25 °C to 50 °C) –13 °F to 122 °F (–25 °C to 50 °C)
Relative Humidity 20-95%, non-condensing 20-95%, non-condensing
Storage**
Temperature –13 °F to 149 °F (–25 °C to 65 °C) –13 °F to 149 °F (–25 °C to 65 °C)
Shelf Life 1.5 Years 1.5 Years
Dimensions
and Weight
NEMA 3R
9-3/4” x 19-3/4” x 5-1/4” : 26 lbs
(25 x 50 x 13 cm) : (11.8 kg)
9-1/8” x 15-3/8” x 11-1/2” : 31 lbs
(66 x 39 x 29 cm) : (14.1 kg)
