Franklin Electric MonoDrive - Models; Applications

PRODUCT INFORMATION
Models
8
Models
SubDrive/MonoDrive Connect Models
Applications
Three-Phase Submersible Applications
Refer to “Pump Sizing and Performance” on page 10 when selecting a pump.
Motor and pump HP are programmed through DIP switch settings. Refer to “Submersible Motor
and Pump Sizes (DIP SW2 & DIP SW3)” on page 27.
Model Part Number Model Part Number Model Part Number
SubDrive 50 5870205503C SubDrive 20 5870205303C MonoDrive XT 5870205203C
SubDrive 30 5870205403C SubDrive 15 5870205103C MonoDrive 5870205003C
Motor and Pump Combinations SubDrive 50 SubDrive 30 SubDrive 20 SubDrive 15
1.0 hp (0.75 kW) 234513-series motor with:
• 0.5 hp (0.37 kW),
• 0.75 hp (0.55 kW), or
• 1.0 hp (0.75 kW) pump

1.5 hp (1.1 kW) 234514-series motor with:
• 0.75 hp (0.55 kW),
• 1.0 hp (0.75 kW), or
• 1.5 hp (1.1 kW) pump

2.0 hp (1.5 kW) 234315-series motor with:
• 1.0 hp (0.75 kW),
• 1.5 hp (1.1 kW), or
• 2.0 hp (1.5 kW) pump

3.0 hp (2.2 kW) 234316-series motor with:
• 1.5 hp (1.1 kW),
• 2.0 hp (1.5 kW), or
• 3.0 hp (2.2 kW) pump

5.0 hp (3.7 kW) 234317-series motor with:
• 3.0 hp (2.2 kW), or
• 5.0 hp (3.7 kW) pump

