78


VFD-10 Skip Freq 1 Enable
Skip Freq 1 Enable
10) Disabled
0 - Disabled
1 – Enabled
Default: Disabled

Skipfrequency1enable/disable.Usedto
bypassmechanicalsystemresonance
frequencies.

VFD-11 Skip Freq 1 Low
Skip Freq 1 Low
11) 23Hz
Min: 0
Max: PRIMARY-7
Default: 23Hz

Skipfrequency1,LowerValuewillappearwhen
SkipFrequency1issettoEnable

VFD-12 Skip Freq 1 High
Skip Freq 1 High
12) 26Hz
Min: VFD-11
Max: PRIMARY-7
Default: 26Hz

Skipfrequency1,UpperValuewillappearwhen
SkipFrequency1issettoEnable

VFD-13 Skip Freq 2 Enable
Skip Freq 2 Enable
13) Disabled
0 - Disabled
1 – Enabled
Default: Disabled

Skipfrequency2enable/disable.Usedto
bypassmechanicalsystemresonance
frequencies.

VFD-14 Skip Freq 2 Low
Skip Freq 2 Low
14) 33Hz
Min: 0
Max: PRIMARY-7
Default: 33Hz

Skipfrequency2,Lowerlimitwillappearwhen
SkipFrequency2issettoEnable

VFD-15 Skip Freq 2 High
Skip Freq 2 High
15) 36Hz
Min: VFD-14
Max: PRIMARY-7
Default: 36Hz

Skipfrequency2,Upperlimitwillappearwhen
SkipFrequency2issettoEnable



VFD-16 Skip Freq 3 Enable
Skip Freq 3 Enable
16) Disabled
0 - Disabled
1 – Enabled
Default: Disabled

Skipfrequency3enable/disable.Usedto
bypassmechanicalsystemresonance
frequencies.

VFD-17 Skip Freq 3 Low
Skip Freq 3 Low
17) 43Hz
Min: 0
Max: PRIMARY-7
Default: 43Hz

Skipfrequency3,Lowerlimitwillappearwhen
SkipFrequency3issettoEnable

VFD-18 Skip Freq 3 High
Skip Freq 3 High
18) 46Hz
Min: VFD-17
Max: PRIMARY-7
Default: 46Hz

Skipfrequency3,Upperlimitwillappearwhen
SkipFrequency3issettoEnable.

FrequencySpeedSetup
Thereare threeconfigurablespeed parameters
thatallowyo utosettheVFDfrequencytopreset
values,asdescribedbelow:

 SpeedA:TheVFDwillswitchitsfrequency
reference to preset frequency‐A in Auto
mode witho
ut PID control, or Hand mode
when DI is set withSpeed‐A activated. If in
AutomodePIDcontrolisenabledandDIset
with Speed‐A activated, nothing will be
changed in VFD operation. Fireman’s
overridemodeoverridespresetspeeds.

 Speed B:Same as above bu
t DI  is set to
Speed‐B.

 Speed AB:If one DI is set to Speed‐A and
another one to Speed‐B and both are
activatedsimultaneously,theVFDwillrunat
the frequency set in ADVVFD‐21. VFD
operationisidenticaltoADVVFD‐19.

