99

Fault Cause
 Remedy
GroundFault(L) Occurswhen:Groundfault
currentexceedstheinternal
groundfaultlevelvalue.
 EnsureMotorandVFDaregrounded
pertheinstallationguide.
 Disconnectmotorwiresfrom
packageandChecktheou tput
wiringandinsulationofmotor
windingswithMeggertester.
BypassMotor
Overload
TheBypassMotorOverload
protectionprovidesmotor
overloadprotectionwhenin
Bypassmodeonly.Ifthe
motorpullsmorecurrent
thansetmotorFLA,itwilltrip
basedonselectedtripclass
topreventmotordamage.
 CheckFLA,TripClass,
 Checkifmotorisoverloaded

BypassPhaseLoss Thebypassdidnotsee
currentinoneormoreofthe
phases.
 Checkwiringpassingthroughthe
bypasscurrentsensorsforloose
connections.
BypassBoardError Thebypassboarderrorisa
“hardfault”andrequiresthat
theboardbepowercycledto
clearit.
 IfPowercycledoesnotclearthe
fault,pleaseconsultfacto ry
BypassStall TheStallfaultoccurswhen
thecurrentexceeds300%of
setFLAfor0.5secandthe
currentslopeisnot
decreasing.(Notactive
duringstartup).
 CheckFLAsettings.
 Checkifmotorisoverloaded.
 Checkformechanicalissues(bad
bearings,badgearsorbelts)
 IfnothinghelpsAdjuststalllevel
higher.(Defa
ultis300%)
BypassMaxTimeto
Start
Amaxtimetostarttrip
occursifthemotorcurrent
hasnotdecreasedbelowFLA
10secondsafterstart.
 CheckthatyourFLAsetti ngin
PRIMARY‐04matchesthemotor
nameplate
 Checkthemotorandsystemfor
mechanicalissues
 Checkyourdipswitchsettings
 Checkpowerwiringforloo
se
connection.
BypassGroundFault AGroundFaultoccurswhen
bypassmoduledetermines 
thatthereisamotorground
leakcurrent.

 Disconnectmotorleadsfrombypass
packageandtestinsulationwith
Megger
 IfMeggerreadingshowslow
insulation,checkmotorwiringand
motorjunctionboxfordamaged
wireinsulationandmoisture


