20 Cyclone PRO User Manual
CYCLONE PRO
Figure 3-18: Via Cyclone PRO Board Power and Pin 6 of Cyclone PRO BDM
Connector
Jumpers 2, 3, and 4 are enabled as shown in Figure 3-19.
.
Figure 3-19: Jumper Settings for Target Power Connection via Cyclone PRO
Board Power and Pin 6 of Cyclone PRO BDM Connector
3.12.4 Using Power IN Jack And MON08 Header Pin 15
A center positive power supply is connected to the Power IN Jack of the
Cyclone PRO. Pin 15 of the Cyclone PRO MON08 header provides the
appropriate voltage for MON08 targets.
