48 Cyclone PRO User Manual
CYCLONE PRO
6 STAND-ALONE PROGRAMMER MANUAL CONTROL
The Cyclone PRO must be configured before it may serve as a Stand-Alone
Programmer for HC08, HCS08, RS08, HC(S)12(X), ColdFire V1 targets. The
user may manually control the Cyclone PRO: via the buttons/LEDs, LCD
menu, or via PC software. The target power management schemes remain
the same for each control method.
6.1 Operation Via Cyclone PRO Buttons
There are five (5) buttons on the top of the Cyclone PRO which are used for
stand-alone programming and to navigate the LCD menus. They are specified
as follows.
Button
Function
START / Start executing the tasks pre-configured into the
Cyclone PRO.
Menu Mode: Navigate upwards in LCD menu.
AUX / Perform auxiliary function (stand-alone verification).
Menu Mode: Navigate downwards in LCD menu.
MENU / [SELECT] Toggles ON/OFF the Target Board Power.
Menu Mode: Select highlighted item in LCD menu.
CANCEL Cancel the tasks being executed and go back to the
standby state.
RESET Hardware reset of the Cyclone PRO.
6.1.1 Cyclone PRO LED Indicators
The Cyclone PRO has eight (8) LEDs to indicate the current operation stage.
LED
FUNCTION
Power Indicates that the target board power is connected.
Standby The Cyclone PRO is waiting for instructions.
Security The Cyclone PRO is trying to pass the target security
and enter monitor mode (for MON08 only).
Erase The Cyclone PRO is erasing the target Flash/
EEPROM.
Program The Cyclone PRO is programming the target Flash/
